Low loader semi-trailer TAD.Classic 70-5 for transportation up to 70 tons

Learn more
Learn more
  • Description
  • Technical characteristics
  • Photo Gallery
  • Video Gallery
  • In action
  • Options
  • View 360 °
  • Financing
  • Compensation 25%
  • Price

Sorry, this section is still under construction


• total length 19680 mm
• length of the lowered platform 8000 mm (telescopic extension is possible)
• width 2550 mm / 3500 mm (extension)
• height: from 200 mm to 500 mm depending on the type of working platform

The weight:

• 70,000 kg loading capacity

Axles and suspension:

• WABCO pneumatic system with ABS / EBS
• axles in the amount of 5 pieces BPW 14t R22.5 with drum brakes
• brake system of drum, disc type with ABS, manufactured by WABCO
• tires Continental R22.5 275 \ 80
• 4а-5а axes are inertial-pidrulny


• preliminary cleaning of metal by shot blasting, sand blasting. Two coats of high quality primer and two coats of damage resistant paint from European manufacturers


• high-quality machine-building steel S690, S350 of domestic or imported production, with high parameters of elasticity and strength
• quality control of welded seams is carried out by the magnetic powder method, by a specialist with the appropriate certificate

The basic model is completed with:

• working platform flooring, 50mm thick wood, sides and boxes.
• telescopic extension 4000 mm long
• rear balcony decking corrugated wood 45 mm thick
• the flooring of the gooseneck is corrugated metal, 5 mm thick.
• hydraulic way of splitting the gooseneck with a platform driven by a car
• WABCO pneumatic system with ABS / EBS
• axles in the amount of 5 pieces BPW 14t R22.5 with drum brakes
• tires Continental R22.5 275 \ 80
• 4a-5a axes are inertial-pidrule
• extension of the platform with metal rails
• lifting eyes for securing cargo with a maximum load of 5300 kg
• rigging straps 4 pcs
• anti-rollback supports 2 pcs.
• flasher 1 piece
• road cone 8 pcs
• spare part 1 piece
• color blue


• the frame structure is guaranteed for 3 years or 150 t km of run
• for other components according to the obligations of the manufacturers

The advantages of OUR trailer

• durable, time-tested construction that can withstand the terrible overloads of bad Ukrainian roads
• high-quality original components from the best manufacturers
• a well-developed design of the trailer that allows you to easily transport most of the goods that the market offers
• simplicity, convenience and reliability in operation
• if necessary, service support and advice from our specialists
• recommendation of the optimal configuration for YOU based on our extensive experience in transporting oversized cargo
• possibility of transporting combines with headers 10 m.
• Price !!! note that it is much lower than the cost of similar European trailers. Moreover, our equipment is more adapted to domestic operating conditions.
• QUALITY !!! our company is one of the largest carriers of oversized cargo in Ukraine and we first of all embody all our practical experience in the equipment of our production. Thanks to this, we never stay in place, but constantly improve ourselves, making the necessary changes in the design of trailers, as required by the market, as well as improving their quality, practicality and reliability.

Standard axles
Understeering axles
Compulsory steered axles
Other options
Additional boxes on the rear platform
Metal flooring in the trailer platform
Telescopic lengthening bar
Trolley "DOLLI"
Autonomous hydraulics of gooseneck

Click on the image to rotate the model

Compensation 25%

To receive compensation, you need to have a bank account with a statutory capital of more than 75% owned by the state of Ukraine

Make a trailer payment at the bank

Submit documents to the bank:

  • a copy of the payment order;
  • an act of reception and transmission of equipment;
  • certificate of state registration of equipment;
  • a certificate, confirmed by the State Fiscal Service, about the absence of arrears for more than six months to the state budget, the Pension Fund of Ukraine, funds of compulsory state social insurance;
  • an extract from the Unified State Register of Legal Entities, Individual Entrepreneurs and Public Associations, information that the enterprise is not in the liquidation phase, it has not initiated bankruptcy proceedings, has not been declared bankrupt;
  • consent to the disclosure by the Bank of the Ministry of Agrarian Policy of information on agricultural producers, which is a bank secret or contains personal data (in the form established by the Bank);

Compensation is returned after entering the data in the register of the Ministry of Agrarian Policy during the day.

Buying TAD low loaders is even more profitable!
