Semi-trailer with the number of axles from 2 to 9. Payload from 20 to 90 tons. The advantage of this type of semi-trailer is a good ratio of its own weight to the weight of the transported cargo. For convenient loading, the trailer can be equipped with mechanical or hydraulic ladders. The platform can be made in different variations depending on the wishes of the client. Metal or wooden flooring is possible, with the possibility of recesses for wheeled vehicles. Platform height from 800 mm, width up to 3200 mm with expanders. For transportation of long loads the option of telescopic extension on 1 – 2 degrees is provided.

SpecificationsDescription
Dimensions:

• total length 14450 mm
• length of the lowered platform from 9450 (14450) mm (telescopic extension)
• width 2550 mm / 3200 mm (expansion)
• height from 760 mm

Weight:

• 14000 kg net weight
• 65,000 kg load capacity

Axles and suspension:

• pneumatic, semi-spring reinforced
• axles stationary, steering, forced control (rotary)
• drum brake system, disc type with ABS, manufacturer WABCO
• paired tires R17.5, R19.5

Dyeing:

• preliminary cleaning of metal by shot blasting, sandblasting. Two layers of high-quality soil and two layers of damage-resistant paint from European manufacturers

Metal:

• high-quality machine-building steel S690, S350 of domestic or import production, with high parameters of elasticity and durability
• quality control of welds is carried out by the magnetic powder method, a specialist with the appropriate certificate

The basic model is completed:

• axles of 10 t are standard
• one inertial driven axle
• GT tires, or similar economy class
• high-strength machine-building steel
• wood flooring platform

Additional options that are not included in the basic set:

• mechanical ramps on springs (removable)
• hydraulic ramps with autonomous drive and / or from the tractor (removable)
• platform extension up to 3200 mm
• telescopic elongation up to 6000 mm
• additional aluminum boards on the butt
• additional box
• lifting axis
• inertial or forcibly controlled axes
• metal decking platform
• 3.5-inch hitch

Guarantee:

• the frame construction is guaranteed for 3 years or 150 t km
• for other components in accordance with the obligations of the manufacturers

Advantages OF OUR trailer

• durable, time-tested construction that can withstand the terrible congestion of bad Ukrainian roads
• high-quality original components from the best manufacturers
• well-designed trailer design that allows you to easily transport most of the goods offered by the market
• simplicity, convenience and reliability in operation
• if necessary, service support and advice from our specialists
• recommendation of the optimal configuration for YOU based on our extensive experience in oversized transportation
• possibility of transportation of combines with reapers of 10 m.
• Cost !!! note that it is much lower than the cost of similar European trailers. Although our equipment is more adapted to domestic operating conditions.
• QUALITY !!! our company is one of the largest carriers of oversize in Ukraine and all our practical experience we first of all embody in equipment of our production. As a result, we never stay put, but are constantly improving, making the necessary changes to the design of trailers, as required by the market, as well as improving their quality, practicality and reliability.
